2010 Cub Cadet Sx3100
Request a Quote Financing Calculator Request a Brochure Financing Form
Click here to view full image.
Request a Quote Financing Calculator Request a Brochure Financing Form
  • OEM Overview
  • Specifications
  • Compare Models
  • Current Promotions

Overview

 Print Brochure

  • 31.2 Gross HP, 3-Cylinder Liquid Cooled Diesel Engine
  • Category I, 3-Point Hitch w/Position Control
  • Selectable 4WD Engagement
  • 540 Rear / 2100 Mid Independent PTO
  • Available with Industrial or Turf Tires
Powertrain
  • Gross HP: 31.2 HP diesel
  • Net HP: 30.0 @2,500 RPM
  • PTO HP (Hyd): 23.5 @2,500 RPM
  • Rated RPM: 2,500 RPM
  • Bore and Stroke: 88mm x 90mm
  • Total Displacement: 100.2 cu. in.
  • Ignition Type: Direct injection
  • Air Cleaner: Dual Dry
  • Lubrication: Full pressure
  • Cooling System: Liquid cooled
  • Number of Cylinders: 3
Capacities
  • Fuel Tank Capacity: 7.1 gal.
  • Cooling System Capacity: 4.1 qt.
  • Engine Oil Capacity: 3.6 qt.
  • Transmission Case Capacity: 4.6 gal.
Maximum Traveling Speed
  • Forward/Reverse High: 14.8 mph
  • Forward/Reverse Low: 5.1 mph
Hydraulics
  • Type: Open center
  • Pump: Trochoid (HST & st. & PTO) + Gear (impl.)
  • Maximum Pump Capacity: 10.1 GPM at 2,500 RPM
  • Pump Capacity (Main): 4.8 GPM at 2,500 RPM
  • Pump Capacity (Steering): 5.3 GPM at 2,500 RPM
  • 3-Point Hitch: Limited Category 1
  • Hydraulic Control System: Position control
  • 3-Point Hitch Lift Capacity @24" Behind: 1,180 lbs
  • Loader Control Valve: Standard
  • Power Steering: Fully hydraulic
Dimensions
  • Wheelbase: 65.2"
  • Width: 55.6" (w/R4)
  • Overall Length w/o 3-Point Hitch: 109"
  • Ground Clearance: 10.6"
  • Weight w/ROPS (approx.): 1,973 lbs
Tire Size
  • Front Industrial/Turf: 23" x 8.5"-12" / 24" x 8.5"-14"
  • Rear Industrial/Turf: 14" x 17.5" / 36" x 14"-15"
Residential/Commercial Warranty
  • Tractor: The Sx 3100 Compact Tractor has a 2-year or 2,000 hour limited warranty
  • Engine/Drive Train: 3-year or 2,000 hour limited warranty
  • Attachments: 1-year limited warranty
Drivetrain
  • Transmission Type: Hydrostatic
  • Rear Differential Lock: Foot pedal operation
  • 2WD/4WD Engagement: Selectable
  • Final Drive: Bevel gear
  • Brake: Wet disc
  • Number of Ranges: 2
  • PTO Type: Independent
  • Rear PTO/RPM (standard): 540/2,495
  • Mid PTO/RPM (standard): 2,100/2,479

Specifications

Engine
Horsepower 31.2 HP diesel
PTO HP 30.0 @2,500 RPM
Rated RPM 2,500 RPM
Specifications
Wheelbase 65.2"
Width 55.6" (w/R4)
Weight 1,973 lbs
Ground Clearance 10.6"
Tire Size Front Industrial/Turf: 23" x 8.5"-12" / 24" x 8.5"-14", Rear Industrial/Turf: 14" x 17.5" / 36" x 14"-15"
General
Fuel Capacity 7.1 gal
Transmission Hydrostatic
Brakes Wet disc
Hydraulics Open center
Drive Type Hydrostatic

Compare Models

 Print








Year 2010
Manufacturer Cub Cadet
Model Sx3100
Style Compact
Engine
Engine Manufacturer
Engine Type
Horsepower 31.2 HP diesel
PTO HP 30.0 @2,500 RPM
Rated RPM 2,500 RPM
Bore and Stroke
General
Fuel System
Fuel Capacity 7.1 gal
Transmission Hydrostatic
Brakes Wet disc
Hydraulics Open center
Drive Type Hydrostatic
Specifications
Wheelbase 65.2"
Height
Width 55.6" (w/R4)
Weight 1,973 lbs
Ground Clearance 10.6"
Tire Size Front Industrial/Turf: 23" x 8.5"-12" / 24" x 8.5"-14", Rear Industrial/Turf: 14" x 17.5" / 36" x 14"-15"
